c21 corrugated steel panel roll forming machine hebei

Price: 9000.0~11000.0 USD
Payment Terms: T/T,L/C;cash
Place of Origin: Hebei, China (Mainland)
inquire
Add to My Favorites
HiSupplier Escrow
Share |

Product Detail

Model No.: c21
Production Capacity: 20 sets per month
Delivery Date: 30 days
Raw Material: Sheet / Plate Rolling
Extra Services: Cut To Length
Certification: CE
Brand Name: xinnuo
Control System: PLC Delta Inverter
Warranty: 12 months
Means of Transport: Ocean,
Packing: simple plastic film protect...
Power: Hydraulic
Machine Type: Roll Forming Machine
Automation: Automatic
Material / Metal Processed: Stainless Steel
Voltage: 380V
Feeding Material: color steel coils

1.CE and ISO certificate
2.easy operation
3.low price and high quality
4.high productivity
5.PLC control system

 1.Technical parameters:
1Name of commodity & specificationXN-C21roof panel roll forming machine
2Main motor power3kw, 3 phase
3Hydraulic motor power3kw
4Hydraulic Pressure10-12MPa
5Voltage380V /3phase/ 50 HZ (or as your requirement)
6Control SystemPLC Delta Inverter
7Main Frame300mm H-Beam
8Backboard Thickness14mm
9Chain Size20mm
10Feeding Materialcolor steel coils
11Feeding Thickness0.3-0.8mm
12Feeding Width1250mm
13Effective width1000mm
14Productivity8-12m/min
15Roll Station14
16Roller Diameter80mm
17Roller material45# steel
18Cutter materialCr12 , quenched
19Cr-Plating Size0.05mm
20Overall Size7500×1400×1500mm
21Total Weight4.0T
22ComponentsManual Uncoiler-------------------1 set
Guiding Platform------------------1 set
Coil Strip Leveler------------------1 set
Main Machine of Roll Forming------1 set
Electric-Motor---------------------1 set
Cutting Device--------------------1 set
Hydraulic Station------------------1 set
PLC Control-----------------------1 set
Supporter Table-------------------1 set
23WorkflowManual decoiling----feeding and guiding----roll forming----cut to length----run out table
24Packagenude in the container
25Minimum order quantity1 set
26Payment termsT/T(30% T/T pay in advance, the remaining 70% pay before ship)
27Delivery time30  working days later after receiving the deposit
All technical parameters can be changed, according to user's need.
